Name: HPHT IIA Type Colorless White Diamond Plate Lab Grown Diamond Plate 111 110 100 Orientation square Round Shape
Brand: Shaper Diamond Technology Co., Ltd
SKU: cs
Price: 100 USD
Availability: InStock

Home Products MCD Diamond

HPHT IIA Type Colorless White Diamond Plate Lab Grown Diamond Plate 111 110 100 Orientation square Round Shape

Product Details:

Place of Origin:	China
Brand Name:	Infi
Certification:	no centification
Model Number:	cs

Payment & Shipping Terms:

Minimum Order Quantity:	3pcs
Price:	100+
Packaging Details:	Carton packaging
Delivery Time:	5-8 working days
Payment Terms:	T/T,Western Union
Supply Ability:	30000

Contact Now

Detailed Product Description

Color:	White	Diamond Size:	1-10mm
Thickness:	0.1-2mm	Color:	Clear
Symmetry:	Excellent	Material:	Diamond
Shape:	Square Or Irregulare	Clarity:	IF (Internally Flawless)
Model:	Diamond
Highlight:	white hpht lab diamond , white lab grown diamond

HPHT IIA Type Colorless White Diamond Plate Lab Grown Diamond Plate 111 110 100 Orientation Square Round Shape

Product Attributes

Color	White, Clear
Diamond Size	1-10mm
Thickness	0.1-2mm
Symmetry	Excellent
Material	Diamond
Shape	Square or Irregular
Clarity	IF (Internally Flawless)
Model	Diamond

Product Description

Developed using HPHT technology (high pressure, high temperature), synthetic HPHT monocrystal diamond (MCD) is achieved by combining a mixture of carbon and transitional metals at very high pressures and temperatures.

Advantages of MCD Diamond:

High hardness and wear resistance
High efficiency and low cost
High surface finish can be obtained on your workpiece

Applications:

Super finishing and Miller finishing for Aluminum, Copper, Brass, Gold, Nickel (Other Non Ferrous metals), Ultra Precision Cutting, Clear Plastics

Specifications

Suggested application	MCD Cutting Tools
Model	JSD23
Crystal growth process	Single crystal HPHT
Color	Yellow and dark yellow
Usage	Cutting tools
Quality	High quality
Feature	Wear Resistant
Applied fields	Industry
Orientation	4pt/100
Shape	Square or round
Size range	1.0mm -7.0 mm
Lateral Dimensions Measured	to smaller side
Edge Orientation	<100> edges
Corner Orientation	<111>
Face Orientation	{100} faces
Lateral Tolerance	'+0.5/-0 mm
Surface Roughness, Ra	Polished, Ra < 30 nm
Thickness Tolerance	+/- 0.05 mm

Shipping Details

Place Of Origin	Hunan, China
Delivery Time	1 - 15 Working Days Base on Order Quantity
Payment Terms	100% Payment In Advance
Shipping Methods	DHL, FedEx, SF Express, UPS, EMS, TNT etc
M.O.Q	Negotiable
Port	Main port in China

Frequently Asked Questions

Q1: How is your quality?

A1: We have a very strict quality control system. We guarantee the high performance of our products.

Q2: What is the Warranty for your products?

A2: For one year from the date of purchase. If any problem occurs due to our manufacturing, we will make prompt response, cover the shipping cost, and send replacement.

Q3: Do you have different quality for different kind of stone?

A3: Yes, according to hardness and characteristics of the stone, we have different typology respectively.

Q4: If we need technical support, can you offer us?

A4: Yes, we have an experienced team offering customers specific advice through our product management staff, engineers and technicians.

Q5: How can we be your agent in our country?

A5: Please provide your detailed company information. We will discuss and propose helpful suggestions to find the best solution for you.

Q6: Do you offer free samples?

A6: Normally we do not offer free samples, but we guarantee our product's quality.
