Name: SCD11 4x0.6x0.6mm Yellow HPHT Diamond Plate With Full Four 90 Degree Corners
Brand: Shaper Diamond Technology Co., Ltd
SKU: SCD11
Price: 1,000.00 USD
Availability: InStock

Home Products MCD Diamond

SCD11 4x0.6x0.6mm Yellow HPHT Diamond Plate With Full Four 90 Degree Corners

Product Details:

Place of Origin:	Hunan, China
Brand Name:	Infi
Model Number:	SCD11

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Packaging Details:	in PVC box then in Carton box
Delivery Time:	5-8 working days
Payment Terms:	T/T,Western Union,MoneyGram
Supply Ability:	2000pcs/month

Contact Now

Detailed Product Description

Diamond Type:	Synthetic (lab Created),HPHT Diamond	Diamond Shape:	Rectangle, Long Strip
Diamond Clarity:	Pure, No Inclution No Defect	Diamond Color:	Yellow, Or Dark Yellow
Diamond Cut:	Laser Cut And Have Full Four 90° Corner	Usage:	Dressing Tools, Record Stylus, Dental And Ophthalmic Tools
Type:	Best Quality Of Single Crystal Diamond Plates	Hardness:	Moh's 10
Highlight:	4x0.6x0.6mm HPHT Diamond Plate , Long strip Yellow HPHT Diamond

SCD11 4x0.6x0.6mm Yellow HPHT Diamond Plate With Full Four 90 Degree Corners

Product Attributes

Diamond type	Synthetic (lab created), HPHT diamond
Diamond shape	Rectangle, Long strip
Diamond clarity	Pure, no inclusion no defect
Diamond color	Yellow, or dark yellow
Diamond cut	Laser cut with full four 90° corners
Usage	Dressing tools, Record Stylus, Dental and ophthalmic tools
Type	Best Quality single crystal diamond plates
Hardness	Moh's 10

Product Description

Our SCD11 yellow HPHT diamond plates are precision-cut from mechanical single crystal MCD into logs, specifically designed to meet the exacting size and shape requirements of dressing tools and other precision applications.

Mechanical single crystal MCD offers exceptional machining properties including:

Maximum hardness (Mohs 10) for superior durability
Extended tool life and high wear resistance
Predictable performance characteristics
Excellent for cutting tools, wire drawing, and super-finishing applications
Ideal for processing non-ferrous metals (gold, silver, copper, aluminum) and hard materials (graphite, carbon fiber, ceramics)

Technical Specifications

Product name:	MCD Diamond logs
Type:	Synthetic (lab created), HPHT diamond
Shape:	Rectangle, long strip
Customized support:	OEM, ODM
Usage:	Dressing tool, Record Stylus, Dental and ophthalmic tools
Color:	Yellow, or dark yellow
Features:	High quality surface finishes
Orientation:	Ordinary 4pt (100 on six sides)
Nitrogen content:	<200 ppm
Lateral Tolerance:	+0.1/-0 mm
Edges:	Laser Cut
Polish:	Upper and bottom polished
Polish Roughness:	Ra < 30 nm
Thickness Tolerance:	±0.05 mm
Selling Units:	Single item
Single gross weight:	0.005 kg

Advantages for Dressing Tools

Our diamond logs maintain consistent width and thickness throughout their entire service life, ensuring:

Unchanging performance characteristics from first to last use
No need for tool manipulation during operation
Reliable, predictable results in precision applications

Packaging & Shipping

Each diamond plate is securely packaged in a sealed plastic bag within a protective carton. Standard delivery time is 3-7 working days after payment confirmation.
