Single Crystal CVD Blades | High-Precision Surgical & Dressing Tools

Product Details:

Place of Origin:	China
Brand Name:	INFI
Model Number:	Surgical Blade Type

Payment & Shipping Terms:

Minimum Order Quantity:	5
Price:	Negotiable
Packaging Details:	Courier Box
Supply Ability:	1000

Contact Now

Detailed Product Description

Single Crystal CVD Blades | High-Precision Surgical & Dressing Tools

Product Overview

Meeting ultra-precision cutting standards, CVD single crystal diamond blades deliver:

Extreme hardness and wear resistance
High strength with elastic modulus
Efficient thermal conductivity
Low friction coefficient
Adhesion prevention
Superior corrosion/chemical stability

Core Innovations

Thermal integrity maintenance
Omnidirectional durability
Reusable design

Technical Specifications

Product name	CVD single crystal diamond blades
Structure	Monodiamond
Application	Can be used for scalpels
Tangent Angle	60° 90° or Customizable
Character	Synthetic diamond
Quality	High quality, standard quality
Thickness	Customizable

Implementation Areas

Ophthalmic/neurosurgical scalpels
Biological microtomes
Industrial milling/cutting tools
Wire drawing die components
Diamond dressing implements
High-pressure water jet nozzles

Commercial Benefits

CVD production technology
Cost-effective solutions (request quotes)
Versatile cutting/dressing applications
Scalable manufacturing output

Precision Tolerances

Available thickness	0.2mm - 3mm
Lateral tolerance	+0.15,-0mm
Thickness tolerance	+0.1,-0.05mm
Face orientation	{100}> or {110}
Crystallographic Orientation (Miscut)	±3°
Surface finish	Polished, Ra<10nm
Edges	Laser Cut
Laser Kerf	<3°
